Olympus Innov-X Delta Classic Plus Handheld XRF Analyzer


Model : Delta Classic Plus

Category: Tag:


Olympus Innov-X Delta Classic Plus

The DELTA Classic Plus with a 40kV tube and Si-PIN detector is ideal for simple applications. The DELTA Classic Plus provides quick ID, screening, sorting, and elemental and metals analysis. The DELTA Classic Plus is a proven, ruggedized analyzer, that is cost-effective, easy to use, and reliable.



  • Powerful 4W X-ray tube, 200 µA current (max), optimized beam settings
  • Tight geometry for exceptional LODs and high analysis throughput
  • Si-PIN detector and customized X-ray tube options for exceptional sensitivity and precision for more elements and materials
  • Patent-pending automatic barometric pressure correction that adjusts calibration as needed for more accurate analysis of light element.
  • Lightning-fast data acquisition for faster testing time
  • Floating Point Processor: Provides more calculations in less time, and leverages more advanced calibration algorithms
  • Integrated Bluetooth® for data input and output available in most countries
  • Integrated wide area heat sinks throughout the DELTA body for high power use in extreme temperatures
  • Analysis indicator lights visible from 360° to help ensure safe use
  • Advanced colortouch LCD screen for clarity, brightness, responsiveness, and energy efficiency for indoor/outdoor use
  • Accelerometer technology puts the unit into sleep mode to save energy when not in use; logs impacts for tool management
  • DELTA PC Software for enhanced data analysis, calibration modeling, and optional closed beam workstation operation
  • USB interface port for high-speed downloads and seamless PC control
  • Ergonomic rubberized handle for enhanced grip
  • Docking Station and Hot Swap Batteries


Specifications Delta Classic Plus :

Excitation Range DELTA Premium 4W Rh, Au, or Ta anode (per application) X-ray Tube
DELTA Professional 4W Ag, Rh, Au, or Ta anode (per application) X-ray tube
DELTA Classic Plus 4W Au or Ta anode X-ray tube
DELTA Element 4W Au anode X-ray tube
Detector DELTA Premium Large-Area Silicon Drift Detector
DELTA Professional Silicon Drift Detector
DELTA Classic Plus Si-PIN Diode Detector
DELTA Element Si-PIN Diode Detector
Analytical Range DELTA Premium Alloy and Mining: Mg and up for Rh/Ag and Al and up for Ta/Au; Soil: P and higher
DELTA Professional Alloy and Mining: Mg and up for Rh/Ag and Al and up for Ta/Au; Soil: P and higher
DELTA Classic Plus Alloy and Mining: Ti and higher; Soil: P and higher
DELTA Element Alloy: Ti and higher
Weight 1.5 kg (3.25 lbs) without  battery
Dimensions 260 x 240 x 90 mm (10.25 x 9.5  x 3.5 in.)
Environmental Temperature Range -10 °C to 50 °C (14 °F to 122 °F)
Processing Electronics 530 MHz CPU with integrated FPU with 128 MB RAM; Proprietary Olympus Digital Pulse Processor (DPP)
Power Rechargeable Li-ion battery;  Hot-swap maintains analyzer per during battery charge
Data Display 32 bit Color QVGA resolution, Blanview transmissive backlit touch screen; 57 x 73 mm (2.25 x 2.9 in.)
Data Storage 1 GB microSD (stores ~75,000 readings)
Data Transfer USB, Bluetooth®


  Standard Accessories Delta Classic Plus

  • Carrying Case
  • Li-ion Battery
  • Electronic User Manual and User Interface Guide and Printed Quick Start Guide
  • Battery Charger
  • MIni-USB Cable
  • 3165 Stainless Steel Calibration Check Reference Coin
  • Ten (10) Spare Windows
  • Integrated Wrist Strap
  • DELTA PC Software
  • Factory Authorized Training and Support

Additional information

Lead Time

5-7 days
